Electrostatic Precipitator
Electrostatic Precipitator
Electrostatic Precipitator
Electrostatic Precipitator


We are Manufacturers, Suppliers, Exporters of Electrostatic Precipitators, ESP and our set up is situated in Pune, Maharashtra, India. Electrostatic Precipitator consists of filtrations & Blowers chamber, Contaminated air is drawn in to the Precipitator, It first passes through a mechanical filter which collects larger partics. The air is than passes through Ionizer where it is subjected to an intense electrostatic field. All the oil mist & Smoke particles receive a strong electrical charge. These charged particle the collector cell having metal plates of opposite electric charge. The grounded plates atttracts & capture the oil mist & smoke particles. An after filter improves air distributions through collections cell and also trops any agglomerated articles that may blow off the cell. A unique high voltage power pack is a special feature.

  • UNITED ELETROSTATIC FILTER collects air pollutants at generation source itself, before it spoils the work-place.
  • Very low running cost, no recurring/ replacement of fiter media cost.
  • Gives clean and healthy working environment for better productivity.
  • UNITED ELECTROSTATIC FILTER can be incorporated in old/new conventional system for better efficiency.
  • Very low pressure drop-reduces energy cost on blower/fan.
  • Life long, washable and reusable filter elements.
Model Airflow CFM / CMH Motor Overall Dimentions in mm
UF – 01 850 / 1400 0.5 HP 700 560 580
UF – 02 1200 / 2000 1 HP 700 650 580
